New Track Mounted Shell and Auger Rig
The first rig of its kind, the new track mounted Dando 1500 LHR combines the practicality of a mini-crawler with the sampling capabilities of a fully featured shell and auger rig.
Fitted with a Hatz silent engine pack the compact rig can be tracked through tight spaces over difficult terrain using the umbilical remote control panel- it is even possible to track the machine in a straight line with the mast up. The height-adjustable mast can be set at four different positions allowing the rig to operate in indoor areas of limited headroom.
Features include:
- One single collapsible unit with detachable legs.
- Umbilical remote control for tracking of the rig.
- Possible to track the rig while the mast is erect.
- Twin mast hydraulic raising rams.
- Single ram mast serrated foot dump.
- Adjustable mast height. This can be set at 3, 3.5, 4 or 4.5 metres high.
- Equipped with a Hatz silent engine.
- Isolator switch for the rig’s two engines.
- Transit bar for keeping mast legs compact when rig is being transported.
- Removable foot brake
Depths:
- 4 Inches: 46m
- 6 Inches: 26m
- 8 Inches: 20m
For more information visit the Dando 1500 Track Mounted page
